Applicable for transferring all varieties of acidic and alkaline chemical solvents in manufacturing facilities including smelters and chemical plants.

key word:

fabric rubber hose

Category:

Fabric rubber hose

Hotline:

+86 15901470995

Mail:hongye@kemaierhose.com

Feedback

Describe

Scope of application: Applicable for transferring all varieties of acidic and alkaline chemical solvents in manufacturing facilities including smelters and chemical plants.

Operating temperature: -30℃~100℃ (continuous) and ≤150℃ (intermittent).

Structure: The inner rubber layer is made of EPDM-based rubber compounds to increase the auxiliary acid and alkali resistance of inert materials; the reinforcing layer is wrapped with multi-layer dipped polyester cloth or cord, featuring adhesion between layers and high pressure resistance; the outer rubber is made of EPDM-based rubber compounds, featuring extremely high weather aging resistance.

Color/texture: cloth texture, wrapped by waterproof nylon fabrics through pressurized winding, featuring higher density, tighter fitting between layers, and better integrity of the hose body compared to plain rubber hose.

Inner diameter mm	Inner diameter inch	Working pressure		Hose length
13	1/2	20bar	Working pressure is customizable	20 M/piece for standard	Customization is supported for length requirements≤20 M
16	5/8
19	3/4
22	7/8
25	1	15bar
28	1-1/16	15bar
30	1-3/16	10bar
32	1-1/4
35	1-3/8
38	1-1/2
40	1-9/16
42	1-5/8
45	1-3/4
48	1-7/8
51	2
57	2-1/4
60	2-3/8	8bar
64	2-1/2
76	3
89	3-1/2
102	4
102-800	Please contact our sales department if you need a larger diameter.
