The inner rubber layer is made of NBR-based rubber compounds, with independent formula design to meet the performance requirements; the reinforcing layer is wrapped with cord and wire frame, with antistatic copper wire; the outer rubber is made of CR-based rubber compounds, which has excellent flame retardation and aging resistance.

key word:

Gas hose

Category:

Gas hose

Hotline:

+86 15901470995

Mail:hongye@kemaierhose.com

Feedback

Describe

Scope of application: gas collection and discharge in coal mining.
Operating temperature: -30℃~100℃ (continuous) and ≤120℃ (intermittent).
Structure: The inner rubber layer is made of NBR-based rubber compounds, with independent formula design to meet the performance requirements; the reinforcing layer is wrapped with cord and wire frame, with antistatic copper wire; the outer rubber is made of CR-based rubber compounds, which has excellent flame retardation and aging resistance.
Color/texture: cloth texture; optional asbestos to further enhance flame retardation, wrapped by waterproof nylon fabrics through pressurized winding, featuring higher density, tighter fitting between layers, and better integrity of the hose body compared to plain rubber hose.

Inner diameter mm	Inner diameter inch	Working pressure		Hose length
13	1/2	20bar	Working pressure is customizable	20 M/piece for standard	Customization is supported for length requirements≤20 M
16	5/8
19	3/4
22	7/8
25	1
28	1-1/16
30	1-3/16	10bar
32	1-1/4
35	1-3/8
38	1-1/2
40	1-9/16
42	1-5/8
45	1-3/4
48	1-7/8
51	2
57	2-1/4
60	2-3/8
64	2-1/2
76	3
89	3-1/2
102	4
102-800	Please contact our sales department if you need a larger diameter.
